Engineering Graphics Essentials - Second Edition

ISBN: 1585032832

Author: Kirstie Plantenberg

Condition: New

The 2nd Edition of Engineering Graphics Essentials will include a new chapter on Isometric Pictorial Drawings. A PDF file of the chapter is available for download by clicking the SampleChapters button under the Download sectionEngineering Graphics Essentials gives students a basic understanding of how to create and read engineering drawings by presenting principles in a logical and easy to understand manner and by having students work through a series of exercises.Table of Contents1. Orthographic Projection2. Dimensioning3. Sectioning4. Tolerancing5. Threads and Fasteners6. Assembly Drawings7. PictorialsAppendix A: Printing to ScaleAppendix B: Title BlocksAppendix C: Symbol Proportion and FormAppendix D: Limits and FitsAppendix E: Threads and Fastener TablesAppendix F: References
