Contemporary Logic Design

ISBN: 0201308576

Author: Katz, Randy

Condition: New

BASIC APPROACHIn the past ten years there has been a revolution in the practice of hardware design. Professionals now rely on CAD software, rapid prototyping, and programmable logic devices to streamline the design process. Contemporary Logic Design is the first text to address these changes - and to offer a truly modern introduction to logic design. Throughout, the author complements his presentation of logic design theory with discussions of current design technologies. Approximately 60% of the book presents new material; the remainder has been re-organized and partially re-written to correspond to the organizational changes.

• 1.1 Dissecting the Title | 1.2 A Brief History of Logic Design | 1.3 Computation | 1.4 Examples | 2.1 Outputs as a Function of Inputs | 2.2 Laws and Theorems of Boolean Logic | 2.3 Realizing Boolean Formulas | 2.4 Two-Level Logic | 2.5 Motivation for Two-Level Simplification | 2.6 Multi-level Logic | 2.7 Motivation for Multi-Level Minimization | 3.1 Two-Level Simplification | 3.2 Automating Two-level Simplification | 3.3 Multi-level Simplification | 3.4 Automating Multi-level Simplification | 3.5 Time Response in Combinational Networks | 3.6 Hardware Description Languages | 4.1 History | 4.2 Basic Logic Components | 4.3 Two-Level and Multi-Level Logic | 4.4 Non-gate Logic | 5.1 Design Procedure | 5.2 A Simple Process Line Control Problem | 5.3 Telephone Keypad Decoder | 5.4 Leap Year Calculation | 5.5 Logic Function Unit | 5.6 Adder Design | 5.7 Arithmetic Logic Unit Design | 5.8 Combinational Multiplier | 6.1 Sequential Logic Elements | 6.2 Timing Methodologies | 6.3 Registers | 7.1 Counters | 7.2 The Concept of the State Machine | 7.3 Basic Design Approach | 7.4 Motivation for Optimization | 8.1 State Minimization/Reduction | 8.2 State Assignment | 8.3 Finite State Machine Partitioning | 8.4 Hardware Description Languages | 9.1 Basic Sequential Logic Components | 9.2 FSM Design with Counters | 9.3 FSM Design with Programmable Logic | 9.4 FSM Design with More Sophisticated Programmable Logic | 9.5 Case Study: Traffic Light Controller | 10.1 A Finite String Recognizer | 10.2 A Complex Counter | 10.3 A Digital Combination Lock | 10.4 A Memory Controller | 10.5 A Sequential Multiplier | 10.6 A Serial Line Transmitter/Receiver | 11.1 Structure of a Computer | 11.2 Busing Strategies | 11.3 Finite State Machines for Simple CPUs | 12.1 Random Logic | 12.2 Time State (Divide and Conquer) | 12.3 Jump Counter | 12.4 Branch Sequencers | 12.5 Microprogramming | Epilogue
