Engineering Graphics: Tools for the Mind & DVD

ISBN: 1585034126

Author: Bryan Graham

Condition: Used

Engineering Graphics: Tools for the Mind is a comprehensive engineering textbook that combines hand sketching, audio/video presentation, and an engineering graphics digital reference book into a single textbook. All audio/video presentations and the engineering graphics digital reference book are contained in a single DVD bundled with the textbook.Engineering Graphics: Tools for the Mind is made up of eight sections. Each section starts with an explanation of the topic covered and is followed by hand sketching exercises for the student to complete. All 76 sketching exercises found in the textbook are printed on perforated paper making it easy for students to turn in for review.The textbook covers the following topics: Lettering Sketching Orthographic Projection Isometric Drawings Oblique Drawings Auxiliary Views Sections Dimensioning Audio/Video Presentation16 separate audio/video lectures address the above topics and show students how to solve select problems contained in the book. To see a sample Audio/Video file from this DVD click below. The size of this file is 182MB and may take several minutes to download.Engineering Graphics Digital Reference Book:Technical Graphics, a 522 page engineering graphics textbook, is included in digital form to give your students reference material for a wide range of engineering graphics topics.Technical Graphics Table of Contents1. Getting Started2. Technical Sketching3. Orthographic Projection4. Pictorial Drawings5. Sections and Conventions6. Dimensions and Tolerances7. Dimensioning for Production8. Fastening, Joining, and Standard Parts9. Production Drawings10. Three-Dimensional Geometry Concepts11. 3-D Geometry Applications12. Graphical Presentation of Data13. Design ProcessAppendix
