Print Reading for Industry

ISBN: 1631260510

Author: Brown, Walter C.

Condition: Used

Print Reading for Industry is a combination text and write-in workbook designed to assist students in reading and understanding industrial prints. This text starts with the basics of print reading and progresses to advanced topics. It presents a thorough discussion of print reading techniques, providing the necessary information and guidance to read the language of industry. Print Reading for Industry includes authentic industrial prints for hands-on learning. Bonus print reading exercises related to the oversized prints in the Large Prints Packet provide additional real-life print reading experiences.Table of ContentsIntroduction to Drafting and Print Reading Procedures1. Prints: The Language of Industry2. Line Conventions and Lettering3. Title Blocks and Part ListsFundamentals of Shape Description4. Geometric Terms and Construction5. Multiview Drawings6. Section Views7. Auxiliary Views8. Screw Thread RepresentationFundamentals of Size Description and Annotations9. Dimensioning10. Tolerancing11. Machining Specifications and Drawing Notes12. Surface Texture Symbols13. Geometric Dimensioning and Tolerancing14. Drawing Revision SystemsIndustrial Drawing Types15. Detail Drawings16. Assembly DrawingsSpecialized Parts and Prints17. Spring and Fasteners in Industrial Prints18. Gears, Splines, and Serrations19. Cam Diagrams and Prints20. Plastic Parts21. Precision Sheet Metal Parts22. Welding Prints23. Instruction and Control Drawings

• Supplement Booklet (10 large prints)
