The Art of Assembly Language Programming Using PIC Technology: Core Fundamentals

ISBN: 0128126175

Author: Schousek, Theresa

Condition: New

The Art of Assembly Language Programming using PIC Technology thoroughly covers assembly language as used in programming the PIC Microcontroller (MCU). Using the minimal instruction set, characteristic of most PIC products, the author elaborates on the nuances of how to execute loops. Fundamental design practices are presented based on Orrs Structured Systems Development using four logical control structures. These control structures are presented in Flowcharting, Warnier-Orr diagrams, State Diagrams, Pseudocode, and an extended example using SysML. Basic math instructions of Add and Subtract are presented, along with a cursory presentation of advanced math routines provided as proven Microchip utility Application Notes.Appendices are provided for completeness, especially for the advanced reader, including several Instruction Sets, ASCII character sets, Decimal-Binary-Hexadecimal conversion tables, and elaboration of ten Best Practices. Two datasheets (one complete datasheet on the 10F20x series and one partial datasheet on the 16F88x series) are also provided in the Appendices to serve as an important reference, enabling the new embedded programmer to develop familiarity with the format of datasheets and the skills needed to assess the product datasheet for proper selection of a microcontroller family for any specific project.The Art of Assembly Language Programming Using PIC Technology is written for an audience with a broad variety of skill levels, ranging from the absolute beginner completely new to embedded control to the embedded C programmer new to assembly language.With this book, you will be guided through the following areas:Symbols and terminology used by programmers and engineers in microcontroller applicationsProgramming using assembly language through examplesFamiliarity with design and development practicesBasics of mathematical knowledge in hexadecimalResources for advanced mathematical functionsApproaches to locate resources Teaches how to start writing simple code, e.g., PICmicro 10FXXX and 12FXXX Offers unique and novel approaches on how to add your personal touch using PICmicro bread and butter enhanced mid-range 16FXXX and 18FXXX processors Teaches new coding and math knowledge to help build skillsets Shows how to dramatically reduce product cost by achieving 100% control Demonstrates how to gain optimization over C programming, reduce code space, tighten up timing loops, reduce the size of microcontrollers required, and lower overall product cost
